Cold-formed steel studs connect to the structural steel beam and metal roof deck via supplier-provided bent plates and gravity connections. A structural steel beam supports the metal roof deck, braced by an angle brace detailed separately. Steel stud framing at the perimeter receives finishes per architectural drawings.
SEE ARCH STL STUDS BY SUPPLIER FINISH, SEE ARCH ANGLE BRACE, SEE DET / (1 SE711) STL STUDS BY SUPPLIER, CONN TO STRUCT BY SUPPLIER MTL ROOF DECK STL BM MTL STUD GRAVITY CONN BY SUPPLIER BENT PL PER DET SEE ARCH SEE ARCH FOR INFO NOT SHOWN, SEE DET / (1 SE711)
