This seismic concrete lower sliding support detail features a truss angle provided by the escalator contractor bearing on a cast-in-place steel plate. An 11-inch vertical dimension establishes the clearance to the overhead structural support. The connection accommodates movement relative to the edge of structural support with pending verification by the escalator contractor.
