Structural · S-GNMFR

Concrete Beam and Slab Intersection Detail

Elements

About this detail

A cast-in-place concrete beam independent of the slab on grade, measuring four feet deep by three feet wide with a three-inch clear cover. The top of the assembly features three layers of eight number eleven bars lapped at contractor option with staggered laps, tied with number four cap ties at twelve inches on center. The bottom includes one layer of four number eight bars similarly lapped and staggered. Side reinforcement consists of three number five horizontal edge bars with lapped splices. The assembly is secured with four-leg number four stirrups spaced at twelve inches typical.
