A steel post bears on a steel beam supporting a cold-formed steel wall above, with quarter-inch stiffener plates on each side aligned with the column. A steel angle brace connects back to a steel joist with a quarter-inch plate and fillet welds. A metal deck bears on the lower steel beam and slotted track assembly, secured with three-sixteenth-inch welds.
T.O.S. VARIES 1/4 1/4 STL JST STL ANGLE STL BM 1/4" STIFF. EA. SIDE - ALIGN W/ COL. 3/16 L3x3x3/8 OR 3/8"x3"x3" BENT MTL DECK MTL DECK STL POST - FOR DETAILS & CALLOUTS IN COMMON SEE C.F.S. WALL 1/4"x4"x4" 3/16 TYP. C.F.S. WALL 2-12 2-12 FOR DETAILS & CALLOUTS IN COMMON SEE 4 S5.32 SUREBOARD SHT'G STL BM SLOTTED TRACK T.O.S. VARIES (3/16) 8 S5.12
