A structural steel angle measuring 3 inches by 3 inches by 1/4 inch and 2 feet long ties the roof framing to an existing concrete beam. A wide-flange beam is positioned per plan alongside the concrete support. A roof joist bears on the assembly, with connection details referenced to another sheet. The roof deck spans across the framing and is secured with a 3/16-inch fillet weld.
3/16 L3 x 3 x 1/4 x 2'-0" W-BEAM - SEE PLAN EXISTING CONCRETE BEAM ROOF DECK - SEE PLAN AND SCHEDULE ROOF JOIST - SEE PLAN FOR CONNECTION SEE DETAIL 3/S202
