A saddle bearing plate measuring 3/8 by 6 inches is recessed into the queen post truss top chord to match the wide flange beam top of steel elevation. Two 4-inch machine screws with countersunk heads secure the plate. Side plates measuring 3/8 by 6 inches are attached with typical complete joint penetration welds. Wide flange beams frame into the assembly using typical shear tab connections per detail 1 on sheet S5.01. Metal deck and hollow structural sections are omitted for clarity.
GRID WIDE FLANGE SHEAR TAB CONN. PER - TYP. SIDE & 3/8x6 - TYP. MTL DECK AND HSS NOT SHOWN FOR CLARITY QUEEN POST TRUSS TOP CHORD PER CJP TYP. 1 S5.01 SADDLE BRG & 3/8x6 RECESSED INTO THE TOP CHORD TO MATCH WIDE FLANGE BM T.O.S. EL. 2 S7.11 (2) 4" MT SCREWS COUNTERSINK SCREW HEAD INTO & TYP. 3"
