Deck support angles are supplied by the structural steel contractor for wide flange, hollow structural section, or boxed columns. A typical L3x3x3/16 angle connects with a sixteen-gauge closure plate, set with a typical three-inch clearance. Notes specify the division of responsibility for supplying the deck support angles.
NOTES: 1. DECK SUPPORT ANGLES TO BE SUPPLIED BY STRUCTURAL STEEL CONTRACTOR W, HSS, OR BOXED COLUMN TYPICAL L3x3x3/16 16GA CLOSURE PL DETAIL C TYP 3"
