A structural steel framing detail showing a patio slab step assembly with a bottom flange kicker brace located at each beam location per detail 3/S531. A standard connection per detail 1/S531 ties the framing together at the beam web. The edge of slab dimensions indicate a 10-inch offset at the upper level and a 9-inch offset at the lower level relative to the grid lines.
____ 6 S752 EOS 9" BOTTOM FLANGE KICKER BRACE PER , AT EACH BEAM LOCATION 3/S531 1/S531 STANDARD CONNECTION PER EOS 10"
