A concrete-filled metal deck bears on structural steel framing sized per plan to create a vertical step in the floor slab. A fourteen-gauge Z-closure shapes the vertical face of the step. Reinforcement consists of number four continuous bars at the top and bottom of the step, supplemented by number four bars spaced at twelve inches on center.
BEAM SEE PLAN TOP OF FLOOR SLAB, SEE PLAN 14 GA Z-CLOSURE #4@12" #4 CONT T&B OF STEP WT FILL BEAM SEE PLAN FOR SIZE SEE SCHED METAL DECK & CONC FILL PLAN SEE 6" SEE SCHED METAL DECK & CONC FILL
