A composite floor deck bears on a wide flange steel beam per plan, secured by three-quarter inch diameter headed stud anchors spaced equally along the beam as shown on the plan. A light gauge cell closure deck from the manufacturer rests beneath the floor slab edge. A fourteen-gauge two-piece edge form provided by the deck manufacturer finishes the perimeter cantilever.
LIGHT GA CELL CLOSURE DECK MFR COMPOSITE WF BM PER PLAN 14 GA EDGE FORM BY DECK MFR COMPOSITE FLOOR DECK PER PLAN 3/4" DIA WHS EQ SPACED ALONG BM - SEE PLAN FOR QUANTITY TWO PIECE EDGE FORM WITH DECK CANTILEVER ON WIDE FLANGE BEAM
