Structural · S-GFKMR

Sill Support Angle at Ground Floor Slab Edge

Materials

Steel

Elements

Floors / Slabs Arches

Connections

Expansion / Slip Connection

About this detail

A continuous sill angle formed by a L3 1/2x3 1/2x3/8 steel angle secured to the face of a concrete slab on grade. The angle is anchored using 1/2 inch diameter expansion anchor bolts spaced at 12 inches on center with a maximum 4 inch spacing from each end. Connection plates and structural steel angles including L4x3x1/4 members are detailed with vertical long slotted holes containing two 3/4 inch diameter A307 machine bolts centered within the plate, fastened with nuts finger tightened and threads spoiled.
