Composite concrete slab and metal deck bear directly on the top flange of a steel support beam. Welded stud anchors are installed through the deck into the beam flange. Minimum bearing dimensions of one inch and three-quarters of an inch are maintained at the beam edge. The metal deck must be installed to allow proper stud installation without field cutting the deck attachment.
INSTALL METAL DECK TO ENSURE PROPER INSTALLATION OF WELDED STUD WITHOUT FIELD CUT OF METAL DECK ATTACHMENT PER SCHEDULE SECTION A-A 1" MIN BEARING 3/4" MIN 1" MIN
