A diagonal brace runs parallel to a steel beam beneath a metal deck and is anchored at each end with a six-inch by three-eighths-inch by six-inch gusset plate. One-inch spacer plates are inserted per note four where indicated. Three-sixteenth-inch fillet welds secure the gusset plates to the structural members typically on three sides. The diagonal brace size is determined per schedule and its spacing per plans, while open web steel joists appear beyond in adjacent framing.
6"x3/8"X6" GUSSET PLATE EACH END STEEL BEAM DIAGONAL BRACE SEE SCHEDULE FOR SIZE & PLANS FOR SPACING OPEN WEB STEEL JOIST BEYOND STEEL BEAM STEEL DECK STEEL BEAM STEEL BEAM OR STEEL JOIST STEEL DECK 6"x3/8"x6" GUSSET PLATE EACH END DIAGONAL BRACE SEE SCHEDULE FOR SIZE & PLANS FOR SPACING 3/16 TYP 3 SIDES 3/16 3/16 TYP 3/16 TYP 3 SIDES 3/16 3/16 TYP TYP 1" SPACER PLATES PER NOTE 4 3 1 STEEL BEAM L L 3 1 3/16 3/16 TYP
