Reinforcing bars are placed around a pipe or conduit sleeve interrupting the top reinforcement of a concrete grade beam or footing. Additional top bars matching the size and quantity of the interrupted bars are placed alongside the penetration with a lap splice. A minimum clearance of 1 1/2 inches is required between the top reinforcing bars and the sleeve. Detail notes specify minimum spacing between multiple sleeves, cover requirements, exterior caulking at the pipe-sleeve interface, and additional shear stirrups required when penetrations coincide with rebar splice locations.
INTERRUPTING TOP REINFORCEMENT d 2 / S05-01 MIN. 1 1/2" DETAIL NOTES: 1. DO NOT CUT REINFORCING AT OR . 2. ONLY CUT INTERRUPTED REINFORCING AT OR . 3. MINIMUM DISTANCE BETWEEN SLEEVES SHALL BE 4x LARGEST SLEEVE DIAMETER. 4. PROVIDE MIN. 2" CLR. BETWEEN SLEEVE AND REINFORCING. 5. CAULK SEAL GAP AT PIPE/SLEEVE INTERFACE ON EXTERIOR SIDE OF GRADE BEAM/FOOTING. 6. IF PIPE/CONDUIT PENETRATION OCCURS AT EITHER TOP OR BOT. AT REBAR SPLICE LOCATION, PROVIDE 2 ADD'L SHEAR STIRRUPS FOR A TOTAL OF 4 SHEAR STIRRUPS ON EA. SIDE OF PENETRATION. NOTE: FOR ADD'L INFO., SEE a a b c d LAP SPLICE ADD'L TOP BARS, MATCH SIZE & QUANTITY OF INTERRUPTED BARS
