A pre-finished hatch door railing system with a gate is anchored directly to a prefabricated single door roof hatch. The hatch features an integrated railing mounted to an eight-inch minimum insulated metal roof curb.
PRE-FINISHED HATCH DOOR RAILING SYSTEM WITH GATE ANCHORED TO ROOF HATCH PREFABRICATED INSULATED SINGLE DOOR ROOF HATCH WITH INTEGRATED RAILING AND 8" MIN. INSULATED METAL ROOF CURB
