An embed base plate features four anchor holes and a rectangular profile aligned to structural grid lines. Six reinforcing bars are equally spaced vertically across a span of one foot eleven inches, while ten reinforcing bars are equally spaced horizontally. The bar lengths are determined by the buckling-restrained brace supplier with a minimum length of one foot seven and one-half inches. Edge distances measure two inches and two and one-half inches typically around the plate periphery.
BASEPLATE TYPE “B” 2 1/2" TYP GRID 11 1/2" BRB SUPPLIER (1'-7 1/2" MIN) LENGTH AS REQ'D BY GRID 2 1/2" TYP 1'-11" (6) BARS EQ SPACED (10) BARS EQ SPACED 2" TYP 2" TYP
