An HSS brace connects to a hollow structural section column and a wide-flange or HSS beam sized per plan. The brace aligns with the work point at the centerlines of the brace and beam. A three-eighths-inch fillet weld connects the members typically at the HSS column. The wide-flange beam is notched as required with a maximum one-half-inch clearance. A brace on the opposite side is omitted for clarity.
CL BRACE CL BM WP HSS BM PER PLAN WF OR HSS BM PER PLAN BRACE ON OPP SIDE NOT SHOWN FOR CLARITY TYP AT HSS 3/8 NOTCH WF BM AS REQ'D MAX 1/2" HSS BRACE PER PLAN
