A suspended piping assembly is anchored against lateral and longitudinal movement. A vibration isolator attaches to the overhead structure above a threaded rod hanger connected to a pipe hanger securing the piping. The vertical hanger rod is reinforced with a rod stiffener angle attached via three rod-to-angle clamps per rod, featuring a snubber plate for an up stop and maintaining a maximum one-quarter inch clearance. Diagonal cables installed slack are anchored to the structure using bolts or concrete anchors and connect to the assembly with swivel connections at both ends and cable clamps, positioned at approximately forty-five degrees. A cross-sectional inset shows the clamping arrangement of the threaded rod and rod stiffener angle.
DETAIL A. B. C. D. CABLE MUST NOT DEFLECT MORE THAN 1" WHEN SUBJECTED TO MAX HAND PRESSURE AT THE MIDPOINT OF SPAN. NO SCALE CLAMP PIPE HANGER PIPING NOTES: ROD STIFFENER ANGLE THREADED ROD NORMAL ANGLE APPROXIMATELY 45° ADJUSTABLE END CABLE CLAMP SWIVEL CONNECTIONS BOTH ENDS ROD TO ANGLE CLAMPS 3 PER ROD SNUBBER PLATE (UP STOP) THREADED ROD VIBRATION ISOLATOR AS REQD INSTALL AT 45° PARALLEL TO PIPE WHERE REQUIRED FOR LONGITUDINAL SWAY BRACING CABLE INSTALLED SLACK, NOTE D BOLT OR CONC AHR (TYP) ROD STIFFENER ANGLE MAX 1/4" CLEARANCE A A DETAILS SHOWN FOR PIPE BRACING. DUCTWORK AND EQUIPMENT BRACING MUST BE SIMILAR. INSULATION OR OTHER COVERING MATERIALS NOT SHOWN FOR CLARITY. BRACING MUST BE FULLY COORDINATED WITH STRUCTURAL FRAMING AND ALL OTHER BUILDING MATERIALS AND SERVICES. E. THE DETAIL IS FOR REFERENCE ONLY. SEE DELEGATED DESIGN SUBMITTALS FOR SPECIFIC DETAILS.
