Structural · S-GA9J3

Typical Concrete Curb Details on Slab or Beam

Materials

Concrete

Elements

Beams Floors / Slabs Arches Site / Paving Reinforcing

Connections

Rebar Splice / Development

About this detail

Typical concrete curb details cast on top of a concrete slab or beam, categorized by curb width into three conditions: curbs wider than twelve inches, curbs greater than six inches up to twelve inches wide, and curbs six inches wide or less with a maximum height of one foot six inches. The supporting concrete surface is roughened for bond, and continuous reinforcing bars of size number four or number five are anchored into the support with dowels spaced at twelve inches on center or ten inches on center depending on the configuration. Additional transverse reinforcing includes number three stirrups or ties spaced at twelve inches on center. The top of the curb elevation and top of the slab elevation are coordinated with architectural and structural plans.
