A wide-flange girt per plan connects to structural supports with two-inch diameter pipe struts positioned at each end of the channel and at eight-foot intervals on center. Structural angles sized L4x4x1/4 attach at each end. Exterior finishes are installed by others.
WF PER PLAN 2" DIA PIPE EA END OF CHANNEL AND @ 8'-0"OC EXTERIOR FINISHED BY OTHERS 18 S-031 L4x4x1/4 EA END 1 1 18C 8 S-031
