The detail illustrates the connection between an HSS roof beam and metal decking, referencing specific welding requirements and HSS-to-HSS connections via detail bubbles. A dimension of 5 inches maximum is specified for the metal decking overhang past the edge of the support beam. Callouts indicate metal decking per plan and HSS beam per plan.
Text on the drawing
MAX 5" DECK WELDING PER METAL DECKING PER PLAN HSS BEAM PER PLAN HSS TO HSS CONN PER 8 S0.4.1 2 S0.3.1
