A stainless steel enclosure joint connects wall plates with half-inch diameter stainless steel countersunk bolts and nuts spaced at twelve inches on center. A quarter-inch by four-inch stainless steel closure plate is welded to one side of the wall plate unless otherwise noted. Stainless steel connection angles are installed on each side of the corner panel, omitted specifically at the corner panel itself. The assembly interfaces with a concrete curb featuring a forty-five-degree corner at the column, secured by bolted connections on each side of the corner panel.
1/4" 2" 1/4" 2" 4" 1 3/4" 1 1/4" 1" 1/4 1/4 2-12 STAINLESS STEEL WALL PLATE 1/4x4" STAINLESS STEEL CLOSURE PLATE WELDED TO ONE SIDE OF WALL PLATE UNO 1/2" Ø SS COUNTERSUNK BOLT AND NUT @ 12" OC STAINLESS STEEL CONNECTION ANGLE STAINLESS STEEL CONNECTION ANGLE OMIT AT CORNER PANEL N3 1'-6" CONCRETE CURB W/ 45 DEGREE CORNER AT COLUMN 6 1/2" 1/2" 2" 4" PROVIDE BOLTED CONNECTION EA SIDE OF CORNER PANEL TYP 3" 1/4" 3" 1/4" 2 SS-300 TYP 4" 2" 1/2" 1'-0 1/16" 1/2" 9" 9"
