A structural steel column is centered on a rectangular base plate with four anchor bolts positioned at the corners. Dimensions verify the bolt spacing at five and one-half inches and eight and thirteen-sixteenths inches verified in the field from centerlines. The column size is sized per plan, and the base plate details are referenced on sheet S-501.
GP0.9 1' - 4" VIF 8 13/16" VIF 8 13/16" VIF 5 1/2" VIF 5 1/2" COLUMN, SEE PLAN BASE PLATE, SEE DETAIL / 3 S-501
