Two sections, Section A and Section B, of a gusset plate connection bear on a base plate with anchor rods. Two-and-one-half-inch stiffener plates are spaced evenly between the anchor rods. Five-eighths-inch fillet welds are specified at the vertical joints, and five-sixteenths-inch fillet welds are typical at the base connection. Dimensions indicate an overall height of two feet three inches for the gusset assembly and anchor spacing of eight inches and one foot zero inches at the base.
(3) SIDES, EA 2'-3" TYP 5/16 5/16 TYP 5/8 5/8 STIFF PL2 1/2, SPACE EVENLY BETWEEN ANCHOR RODS SECTION A 2'-3" TYP 5/16 5/16 TYP 5/8 5/8 STIFF PL2 1/2, SPACE EVENLY BETWEEN ANCHOR RODS SECTION B 8" 1'-0" 8" 8" 1'-0" 8"
