An aligned flange thickness transition in a steel member incorporates a 2.5 to 1 taper profile welded with complete joint penetration. A cover plate is attached with typical edge welds. The bottom flange employs the top flange configuration opposite.
TYP ES t COVER PL SECTION ALIGNED FLANGE THICKNESS TRANSITION CP NOTE: BOTTOM FLANGE SHOWN, TOP FLANGE OPPOSITE 2.5 1
