An HSS8x8 post bears on a base plate detailed per standard connection requirements and note one. A three-eighths inch plate measuring one and three-quarters by six and one-half inches, four feet zero inches long, connects to each side of the web with typical three-eighths inch fillet welds. A complete joint penetration weld secures the structural components, complemented by a type C1 connection.
TYP NOTES: HSS8x8 POST BASE PL PER TYP DTLS, SEE NOTE 1 TYPE C1 CONN, TYP CJP TYP 3/8 3/8 PL1 3/4 x 6 1/2, 4'-0" LONG, ES OF WEB
