The heavy concrete pier contains twelve three-inch diameter Dywidag anchors with a yield strength of 120 KSI located per base plate details. Sixteen number 10 vertical reinforcing bars of ASTM A706 grade 80 steel run vertically through the pier section. Vertical bars feature a 90-degree hook or headed bar termination at the top with bends executed as needed to clear anchors.
(12) 3.0" DIA. DYWIDAG ANCHORS Fy = 120 KSI SEE BASE PLATE DETAILS FOR ANCHOR LOCATIONS TYP BEND BAR AS NEEDED HEADED BAR OR 90 DEGREE HOOK (16) #10 VERT BARS A706 GR 80
