A pre-bent three-quarter inch diameter threaded rod anchor connects to a vertical core wall element using a downward drilled and epoxy grouted dowel where access is available from above framing. A rebar coupler is provided as required to splice the reinforcement.
CONDITION AT ANCHORS NEAR CENTER CORES E NOTES: 1. SEE NOTES AT CONDITIONS A - D NOTES: 1. 2. COUPLER AS REQ'D DRILL & EPOXY DOWEL DOWNWARD WHERE ACCESS IS FROM ABOVE FRAMING 2 1 PRE-BENT 3/4" Ø T.R. NOTES: 1. SEE NOTES AT CONDITION A & B. L C
