Concrete masonry unit wall reinforcing details show bar placement at each face and at the center of the masonry cells. Vertical reinforcing bars are positioned with a one-half inch clear tolerance from the interior face and one inch tolerance vertically. Bar positioners are spaced at eight feet on center maximum with lap bars per schedule. Size and spacing of reinforcing bars are referenced to elevations.
EQ EQ TOL. = 1"± TOL. = 1"± TOL. = 1/2"± RE: ELEVS FOR SIZE & SPACING BAR POSITIONER AT 8'-0" O.C. MAX. LAP BARS PER SCHEDULE RE: ELEVS FOR SIZE & SPACING BAR POSITIONER AT 8'-0" O.C. MAX. LAP BARS PER SCHEDULE BARS @ EACH FACE BARS @ CENTER 1/2" CLEAR
