Reinforcing requirements for concrete masonry unit wall lintels across different span conditions. Spans from zero to five feet require an eight-inch deep lintel, spans from five to eight feet require a sixteen-inch deep lintel, and spans from eight to twelve feet require a twenty-four-inch deep lintel. Two fifteen-millimeter minimum bars serve as bottom reinforcing, supplemented by vertical reinforcing as detailed on the structural drawings.
8" DP LINTEL 16" DP LINTEL 24" DP LINTEL 8' to 12' SPAN 5' to 8' SPAN 0' to 5' SPAN LINTEL REINF AS PER. WALL ELEV'S AND GENERAL NOTES 2-15M MIN VERT REINF H1E SEE DWG'S 1702 TYPICAL LINTEL
