An HSS 6" x 6" x 3/8" support post is connected to a steel grade beam by others using four 3/4-inch-diameter A325 bolts. A W14 cross member frames into the web member, with support locations spaced per the architect. A possible kicker is provided where it occurs, featuring stiffener plates and welded connections.
STIFFENER PL W14 CROSS MEMBER WEB MEMBER POSSIBLE KICKER (WHERE OCCURES) STL GRADE BM BY OTHERS (4) 3/4" Ø A325 BOLTS HSS 6" x 6" x 3/8" SUPPORT POST AT ________ OC SUPPORT LOC BY ARCH 3 1/6" MAX S404 D5 TYP S404 D5 TYP
