Precast concrete wall panels connect using a hot-dipped galvanized angle measuring 8x4x1/2 by 1 foot 2 inches long. The angle fastens to each concrete panel with two 1/2-inch diameter Hilti KB-TZ expansion anchors. Panel reinforcement is sized per plan with number 5 reinforcing bars.
