A double tube hollow structural section elevator spreader beam connection is located at the top and bottom. The assembly utilizes two 7/8 inch diameter A325 bolts with standard holes per connection. A leave-out panel is provided on one side only. The connection is similar to a single tube condition.
(2) 7/8" DIA A325 BOLTS. PROVIDE STD HOLES PROVIDE LEAVE-OUT PANEL (1) SIDE ONLY CONN SIM TO SINGLE TUBE CONDITION 4-12 4-12 DOUBLE TUBE HSS SPREADER BEAM, T&B 2 TYPICAL ELEVATOR SPREADER BEAM CONN (2) 7/8" DIA A325 BOLTS. PROVIDE STD HOLES PROVIDE LEAVE-OUT PANEL (1) SIDE ONLY CONN SIM TO SINGLE TUBE CONDITION 4-12 4-12 DOUBLE TUBE HSS SPREADER BEAM, T&B 2 TYPICAL ELEVATOR SPREADER BEAM CONN
