This structural connection detail shows a bolted plate assembly connecting to a steel column or wall. The plate length is determined by the number of stud rows with a one-foot minimum. Edge distances measure one and a half inches typically, with a four-inch on-center spacing between bolt rows. A five-sixteenths fillet weld joins the assembly with seven-eighths return welds at the top and bottom.
SECTION A SECTION B 1' - 3" 1 1/2" 6" 6" 1 1/2" 4" OC 1 1/2" 1 1/2" STUDS, 1'-0" MIN PL LENGTH IS BASED ON NUMBER OF ROWS OF 3" MIN FOR COLUMN 18" MIN FOR WALL 1' - 0" 1' - 0" 2 BOLT DETAIL TYP 1 1/2" TYP 1 1/2" 3" MIN FOR COLUMN 18" MIN FOR WALL TYP W/ 7/8" RET T&B SEE NOTE 6 5/16
