Reinforcing bar splice requirements for concrete beams and columns at supports. Bars extend straight unless a standard hook is required, with clear spacing maintained at one-and-one-half inches or wired in contact. Lap splices utilize development length Ld or Class A splices with minimum lengths of twelve bar diameters or twelve inches. Offset reinforcing bars transition within a maximum slope of one to six.
BOUNDARY, COLUMN AND BEAM REINFORCING SPLICE DETAIL A *1 1/2" OR WIRED IN CONTACT FACE OF SUPPORT COLUMN OR WALL REINFORCING BAR BOTTOM REINF 1 MAX 12 SMALLER TOP REINF EXTEND BAR STRAIGHT UNO PROVIDE STANDARD HOOK WHERE NECESSARY "Ld" CLASS "A" LAP SPLICE 12" MIN 12d OR * * "Ld" 12" MIN 12d OR BEAM LARGER TOP REINF COLUMN 6 1 MAX 12" MIN 12d OR LAP SPLICE *
