Two standard steel cap plate configurations are detailed with dimensional callouts for plate width, bolt spacing, and edge distances. Cap plate type one features a symmetrical four-bolt layout welded to the top of a hollow structural section column. Cap plate type two utilizes a two-bolt offset configuration fastened to a hollow structural section member. Dimension lines indicate edge distances and bolt centers for fabrication reference.
'co' 'co' 'ed' 'ed' 'bc' 'ed' 'ed' 'co' 'co' 'ed' 'ed' 'bc' 'ed' 'ed' 'co' CAP PLATE . 1 'w' CAP PLATE . 2 'w' STEEL CAP PLATE TYPES:
