This structural plan detail shows a buckling-restrained braced frame column base plate connection with perimeter anchor bolts and welded column flanges and web. The column is centered on a rectangular base plate with dimensions and anchor bolt spacing defined by schedule. Five-eighths-inch fillet welds connect the column web and flanges to the base plate, with specific sizing callouts along the flange connections. Gridlines intersect at the column axes to establish alignment.
PLAN FRAME COLUMN SEE SCHEDULE WIDTH SEE SCHEDULE LENGTH 5/8 WEB 5/8 COL FLANGE TO BASE PL TYP TF/2 +1/8 EQ EQ TYP 4" EQ EQ
