Framing around a central steel column consists of intersecting steel beams connected with framing angles and bolts. Steel angles measuring L3x3x1/4 are installed where required to provide adequate deck bearing. A designated area is reserved for a roof drain, piping, or conduit, requiring size and location coordination with mechanical and electrical drawings. Three-sixteenth-inch fillet welds are specified typically at the angle connections.
TYP FLR-Deck at Column (Plan) 3/16 TYP STEEL BEAM ROOF DRAIN, PIPING OR CONDUIT. COORDINATE SIZE AND LOCATIONS WITH MECH/ELEC DWGS STEEL BEAM STEEL BEAM STEEL BEAM L3x3x1/4 STEEL ANGLE SHALL BE INSTALLED WHERE REQ'D TO PROVIDE DECK BEARING
