An underside joist and truss elevation at elevation 106.500 meters supports a wide flange W250 crane beam at elevation 105.525 meters. Vertical hollow structural section HSS102x102 hangers, designated PH-1 per drawing S-MB-6.01, extend downward to support an exhaust hose reel. The assembly incorporates hollow structural section HSS152x102 long-span joists, channel sections C100 and C200x17, and angle bracing including L51x51 and L76x76 shapes.
U/S JOIST & TRUSS EL 106.500m U/S STEEL EL 105.525m HSS102x102 HANGER PH-1, SEE DWG S-MB-6.01 EXHAUST HOSE REEL L76x76 C200x17 C100 L51x51 BRACING HSS152x102 (LLH) CRANE W250
