Steel deck bears on bent plates made of ASTM A36 steel with 3-inch by 3-inch legs supported by wide-flange steel beams. Shear studs of three-quarter inch diameter are typically spaced at twenty-four inches on center maximum unless noted otherwise. For angles and webs less than or equal to one-quarter inch thick, one-half inch diameter by four-inch studs are used at twelve inches on center. The deck spans in either direction as indicated on plans, and roof deck installation follows similar criteria.
NOTES: 1. STUDS ARE TYPICALLY 3/4 INCH DIAMETER AT 24 INCHES ON CENTER MAXIMUM, UNLESS NOTED OTHERWISE. 2. AT ALL ANGLES AND WEBS LESS THAN OR EQUAL TO 1/4 INCH THICK, USE 1/2 INCH DIAMETER x 4 INCH STUDS AT 12 INCHES ON CENTER. 3. DECK SPANS EITHER DIRECTION, SEE PLANS. 4. ROOF DECK SIMILAR. BENT PL1/4 (A36) 3" 3" BENT PL1/4 (A36) 3" 3" 4-8 4-8
