Structural opening requirements in a concrete-filled metal deck assembly. A cluster of small openings is treated as a single larger opening for reinforcement purposes. Dimensional limits specify a maximum two-foot spacing and a typical one-and-a-half-inch clearance. Reinforcing bars are designated for concrete-filled decks only.
SECTION AT CONCRETE FILLED DECK #4 AT CONCRETE FILL DECKS ONLY CLUSTER OF SMALL OPENINGS SHALL BE CONSIDERED AS ONE OPENING 1 1/2" TYP. PLAN 2'-0" 2'-0" 2'-0" MAX.
