A monolithic concrete curb and slab assembly features top and bottom slab reinforcement sized per plan, with the top slab rebar terminating in a standard hook into the curb. The concrete curb contains beam reinforcement ties spaced per table and standard corner rebar detailing. Clear cover is maintained at one inch for the top and bottom slab reinforcement and one and one-half inches typically for the curb boundaries.
"H" "W" TOP SLAB REINF, PER PLAN w/ STD HOOK 1" CLR 1" CLR BOTTOM SLAB REINF PER PLAN BM REINF TIES PER TABLE TYP 1 1/2" CLR
