A buckling-restrained brace spans diagonally between a typical steel beam and column frame. The assembly features a central steel core surrounded by a casing and terminates at typical gusset plate connections at each end. Typical steel beams and columns frame the perimeter of the bay. Hatched regions designate the protected zone within the framing.
INDICATES PROTECTED ZONE BEAM, TYP. COLUMN, TYP. GUSSET PL TYP. BRB END CONNECTION TYP. BRB CASING STEEL CORE
