A metal roof deck bears on a structural steel beam near a grid line where the deck spans in the opposite direction. Structural bracing connects to the web of the steel beam, maintaining a specified dimension "X" from the bottom flange. The edge of the deck attachment is welded to the beam flange. For additional information not shown in this view, reference the floor deck detail.
METAL ROOF DECK SPANS OPPOSITE DIRECTION AT SIM. GRID PLAN REF. EDGE OF DECK ATTACHMENT "X" NOTE: FOR INFORMATION NOT SHOWN REF. FLOOR DECK DETAIL. ROOF DECK BRACING
