Stud rail ends align with the face of the concrete column typically unless noted otherwise. The layout features two equal spaces along the orthogonal axes with precise spacing increments of 7 3/8 inches and 8 3/8 inches. The stud rails extend outward from the column periphery to provide shear reinforcement in the concrete slab.
DETAIL I11 STUD RAIL ENDS AT FACE OF COL. - TYP. EDGE OF STUD RAILS TO BE IN LINE W/ COL. FACES U.N.O. (2) EQ. SPACES (2) EQ. SPACES 7 3 /8 " 7 3 /8 " 8 3/ 8 " 8 3/ 8 " 8 3/ 8 "
