A box header connects to a cold-formed steel jamb stud using a plate on each side matching the header gauge and depth, secured with three number ten sheet metal screws each side for a total of six. Alternatively, the header web can be extended on each side to the jamb stud in lieu of a separate plate. Top and bottom clips made of L2x2x12 gauge angles matching the stud depth attach to the box header with three number ten sheet metal screws each face.
JAMB PER SCHEDULE PL TO MATCH HDR GA AND DEPTH EA SIDE (SEE NOTE) (3) #10SMS TYP (6 TOTAL) BOX HDR PER SCHED L2x2x12 GA x STUD DEPTH TOP/BOT W/ (3) #10 SMS EF NOTE: IN LIEU OF PL EA SIDE, EXTEND HDR WEB EA SIDE TO JAMB STUD TYP 1" HDR TO JAMB CONNECTION D
