A W14x43 structural steel shape connects to a W14x82 member utilizing a 1-1/4 inch thick connection plate positioned at the workable gage per AISC standards. Five-sixteenth inch fillet welds attach the assembly typically on each side with a one-quarter inch weld size indicated at the top flange. Fasteners are arranged symmetrically about the centerline per the specified dimensions and note references.
SECTION 5/16 5/16 (1/4) W14x43 TO W14x82 CL PL1 1/4 PER AISC WORKABLE GAGE Lp, SEE NOTE 3 5/16 TYP ES (t) SECTION 5/16 5/16 (1/4) W14x43 TO W14x82 CL PL1 1/4 PER AISC WORKABLE GAGE Lp, SEE NOTE 3 5/16 TYP ES (t)
