An exterior concrete column rises from a concrete footing, tied with dowels matching the vertical reinforcement in the column above. A concrete slab-on-grade terminates at the column via a blockout filled with expansion joint filler material and a control joint. A concrete curb is located beyond the exterior slab or grade, which sits at a minimum thirty inches above the footing base. The foundation components consist of poured concrete footings and slabs bearing on prepared subgrade.
CONC FTG CONC FTG CONC SOG BLOCKOUT AROUND COL DOWELS TO MATCH VERT REINF IN COL ABV CONC COL SEE PLAN COL CONC CURB BYND EXT SLAB OR GRADE ARCH SEE 30" MIN SEE PLAN EXPANSION JOINT FILLER MATERIAL CONTROL JOINT
