An angle frames into a wall where a structural beam connects, maintaining a two-inch typical dimension and a two-inch minimum to six-inch maximum spacing. A three-inch maximum typical dimension applies to the framing condition. The accompanying diaphragm reinforcement schedule specifies location, bar type, and spacing.
3" MAX, TYP ANGLE BM FRAMING INTO WALL ANGLE SECTION 2" TYP 2" 2" MIN, 6" MAX, TYP DIAPHRAGM REINF SCHEDULE LOCATION BAR TYPE SPACING - - -
