An operable partition post is welded to a 14-inch by 8-inch by 1/2-inch base plate using a three-sixteenths-inch fillet weld. The base plate is anchored to a concrete slab using four three-eighths-inch diameter Hilti Kwik Bolt TZ-2 expansion anchors with a three-inch minimum embedment.
TYP 1 1/2" 14"X8"X1/2" BASE PL (4) 3/8" DIA HILTI KWIK BOLT TZ-2 WITH 3" MIN EMBEDMENT 3/16
